VIZ450 Explosion-proof Automatic Sprinkler Device

Key Features:

Dual explosion-proof certification with ATEX & IECEx, marked Ex db IIC T6 Gb / Ex tb IIIC T80℃ Db.
Protection level: IP66
Built-in power and water system provides a stable water source for the PTZ wiper.
The water tank capacity is up to 15L, with long service life and easy installation and maintenance
Made of 304/316L stainless steel for use in chemical, acidic, and other highly corrosive environments.

Features

Use environment

It has class IIA, IIBand IIC combustible gases, and the ignition temperature group is zone 1 and zone 2 of T1-T6 group. Places where combustible gases or vapors form explosive mixtures with air,
2. It is also applicable to areas 21 and 22 with ignition temperature group T1-T6 and places containing combustible dust mixture.

Such as: petroleum, chemical industry, mine, military industry, medicine, oil depot, ship, drilling platform, gas station, fireworks production, grain processing and storage, etc.

Technical parameters

Explosion-proof Sprinkler Device
Explosion-proof mark	Ex db IIC T6 Gb/Ex tb IIIC T80℃ Db
Protection grade	IP66
Working principle	Built-in power system and water storage device, providing a strong water source for washing window glass with explosion-proof PTZ wipers
Water flow speed	500mL/min
Water flow vertical height	＞10m
Water spray volume per time	40mL
Water tank capacity	15L
Water pipe material	304 stainless steel
Water pipe specification	8mm outer diameter, 1mm wall thickness
Water pipe inner diameter	6mm
Water pipe length	10m (customizable)
Cable interface	1x M251.5、M321.5、NPT3/4、NPT1（optional）
Cable length	10m
Weight	Empty box: 20kg; full box: 35kg
Dimensions	Length 436width 202height 652mm
Operating temperature	-15℃~+60℃
Casing material	304, 316L stainless steel (optional)
Operating voltage	DC24V 2A
Installation method	Platform installation
Installation hole position	4 Ø9mm mounting holes
